Chapter 4 4-7
D200/D210/D310 Front Panel LCD Codes
TEST 10D1 MIOC_EIR MIOC External Interrupt Register test.
TEST 10D2 MIOC_HPMC Test I/O HPMC.
TEST 10D4 MIOC_MEM_INTERFACE Tests some of the corner cases of the
memory interfaces, notably the load and
clear word instructions
TEST 10D7 MIOC_EDC_SBE Tests the error detecting &correcting
circuitry for single-bit errors
TEST 10D7 MIOC_EDC_SBE_ERROR Failure occurred in single- bit error
detecting &correction
TEST 10D8 MIOC_EDC_DBE Tests the error detecting for double-bit
errors
TEST 10D8 MIOC_EDC_DBE_ERROR Failure occurred in double-bit error
detection
TEST 10D9 MIOC_PARITY Tests parity Generation/Check of MIOC
GCS interface
TEST 10DA QUICK_TEST Quick destructive RAM Test
TEST 10DB DESTRUCTIVE_TEST Normal destructive RAM Test
Ostat Code Name Meaning
