4-16 Chapter 4

D200/D210/D310 Front Panel LCD Codes

FLT 8407 LASI_FLT_KYBD MFIOC keyboard failure.

TEST 8407 LASI_TEST_KYBD Test MFIOC keyboard.

INIT 8407 LASI_INIT_KYBD Initialize MFIOC keyboard.

TEST 8500 WAX_EISA_MAP_TEST Test EISA bus converter map.

WARN 8500 WAX_EISA_MAP_ERR Error in EISA bus converter map.

TEST 8501 WAX_EISA_ID_TEST Test EISA bus converter ID.

WARN 8501 WAX_EISA_ID_ERR Error in EISA bus converter ID.

Ostat Code Name Meaning
