5-10 Chapter 5

Dx50/Dx60 Front Panel LCD Codes

TEST 2xA7 Starting PM cache CAM selftest

FLT 2xA7-2xA8 PM CAM selftest failure

FLT 2xB0 Dcache parity error

FLT 2xB1 Dcache parity error in tag

FLT 2xB2 Dcache parity error in word 0

FLT 2xB3 Dcache parity error in word 1

FLT 2xC0 Icache parity error

FLT 2xC1 Icache tag parity error

FLT 2xC2 Icache word0 parity error

FLT 2xC3 Icache word1 parity error

Ostat Code Description (Where x = CPU number)
