5-12 Chapter 5

Dx50/Dx60 Front Panel LCD Codes

FLT 3x1C Failed software ID update

TEST 3xBC Sets clock speed

INIT 3xBC Sets clock speed

INIT 30C4 Clearing and revalidating EEPROM

TEST 3xCD Checking stable storage is valid

INIT 3xCD Initializing stable storage

FLT 3xCD Fatal error initializing stable storage

INIT 30D4 Setting EEPROM2 defaults

FLT 30F4 Number of boots exceeded 95,000

FLT 30FC Bad Processor board

FLT 30FD Bad System board ID

FLT 30FF Failure of one or more fans

Ostat Code Description (Where x = Processor Memory bus slot number)
