Chapter 6 6-15
D270/D370, D280/D380/R380 and D390/R390 Front Panel LCD Codes
NOTE
The PDCE_HPMC Memory Fault Codes above are only used in PDC
versions 21 and greater. In PDC versions before that, the PDCE_HPMC
handler used the same Memory Fault Codes as the Memory selftest.
FLT 7D05 Processor Memory bus parity fault (HPMC)
FLT 7D06 Write bomb fault (HPMC, earlier write transaction to memory had a bus
parity error)
FLT 7D07 Memory address fault (HPMC)
FLT 7D08 Multi-bit memory fault (HPMC)
FLT 7D09 Single bit memory fault (HPMC)
FLT 7D0A Address did not map to bank (HPMC)
FLT 7Fxy x = memory carrier card number, y = SIMM pair number
Ostat Code Description
