D270/D370, D280/D380/R380 and D390/R390 Front Panel LCD Codes

INIT 8406 Initialize the MFIOC LAN

FLT 8406 Failed MFIOC LAN test

TEST 8407 Test MFIOC keyboard

INIT 8407 Initialize MFIOC keyboard

FLT 8407 Failed MFIOC keyboard test

FLT 84FF No MFIOC present

TEST 8500 EISA bus converter map test

WARN 8500 EISA bus converter map error

TEST 8501 EISA bus converter ID test

WARN 8501 EISA bus converter ID error
