Dx20/Dx30 Front Panel LCD Codes

FLT 2127 P2 data fault in SLC card slot B

FLT 2128 P2 data fault in SLC card slot A

FLT 2129 P2 data hit from SLC

FLT 212A P2 SLTEADD address mismatch

TEST 2130 Tag comparator and RAM pattern tests

FLT 2132-2138 Tag test faults

TEST 2140 Tag miss test

FLT 2141-2144 Tag miss test faults

TEST 2150 SLC invalidation selftest

FLT 2151-2159 SLC invalidation selftest faults

TEST 2160 SLC error detection and correction selftest

FLT 2161-2177 SLC error detection and correction selftest faults

TEST 2190 SLC DMA selftest

FLT 2191 SCSI initialization fault during DMA test

FLT 2192-2196 SLC DMA selftest faults

INIT 21F0 Starting SLC initialization
