Dx20/Dx30 Front Panel LCD Codes

FLT 301C Failed software ID update

TEST 30BC Sets clock speed

INIT 30BC Sets clock speed

INIT 30C4 Clearing and revalidating EEPROM

TEST 30CD Checking stable storage is valid

INIT 30CD Initializing stable storage

FLT 30CD Fatal error initializing stable storage

INIT 30D4 Setting EEPROM2 defaults

FLT 30F4 Number of boots exceeded 95,000

FLT 30FC Bad Processor board

FLT 30FD Bad System board ID

FLT 30FF Failure of one or more fans
