HP 9000 Series Service Manual

A-4 Appendix A
System Specifications
Table A-8 Electromagnetic and Electrostatic Specifications
Table A-9 Physical Specifications - D Class
Table A-10 Physical Specifications - R Class
+5V Nominal - 5% Nominal + 5% 5.0A 55.0A 50mV P-P
+12V Nominal - 5% Nominal + 5% 1.0A 10.0A 120mV P-P
Aux +5V Nominal - 5% Nominal + 5% 0.0A 55.0A 250mV P-P
Nominal
Voltage
Minimum
Voltage
Maximum
Voltage
Minimum
Current
Maximum
Current
Peak to Peak
Ripple
Description Specification
Radiated Field Immunity 3V/meter, 26MHz to 1 GHz
Magnetic Field Immunity 1 gauss, 47.5Hz to 198Hz
Electrostatic Discharge Immunity
15kV air discharge (maximum, with no
loss of function)
25kV air discharge (maximum, with no
component damage)
Electrostatic Contact Discharge 4kV, no effect
Description Specification
Height 60.4 cm (24.2 in.)
Width 25.9 cm (10.4 in.)
Depth 55.1 cm (22.04 in.)
Weight 49.2 kg (109.1 lb.)
Description Specification
Height 26.0 cm (10.4 in.)
Width 47.5 cm (19.0 in.)
Depth 75.0 cm (30.0 in.)
Weight 36.0 kg (80.0 lbs)
