Appendix B B-35

Support Information

"ERROR: Error occurred getting memory

information"

If a failure occurs while getting memory

information

"ERROR: The stop boot flag is set - can't leave

the user interface to attempt to boot."

If the user is attempting to boot and the Stop

Boot flag is set

"ERROR: An error occurred accessing the

chassis codes queue"

If a failure occurs while attempting to read

from chassis codes queue:

Error Message Definition Description
