HP 9000 Series - Page 465

To Next Page

To Previous Page

Appendix C C-11

HotSwap Disk Bay (D Class Only)

Manual HotSwap Procedure

Customers using manual hot swap on 10.01 Operating System, will need to pick up two

LVM patches to install on their system. There will be two documents included with every

Model D Class Enterprise server informing the customer of the patch and the manual

procedure.

With 10.10 Operating System or later, the LVM patches will be included in the OS.
