HP A5120 EI Series Configuration Guide

150
To do…
Use the command…
Remarks
Clear the GARP statistics on ports
reset garp statistics [ interface interface-
list ]
Available in user view
GVRP configuration examples
GVRP normal registration mode configuration example
Network requirements
As shown in Figure 46:
 Device A and Device B are connected through their GigabitEthernet 1/0/1 ports.
 Enable GVRP and configure the normal registration mode on ports to enable the registration and
deregistration of dynamic and static VLAN information between the two devices.
Figure 46 Network diagram for GVRP normal registration mode configuration
GE1/0/1
GE1/0/1
Device A Device B
Configuration procedure
1. Configure Device A.
# Enable GVRP globally.
<DeviceA> system-view
[DeviceA] gvrp
# Configure port GigabitEthernet 1/0/1 as a trunk port, and assign it to all VLANs.
[DeviceA] interface gigabitethernet 1/0/1
[DeviceA-GigabitEthernet1/0/1] port link-type trunk
[DeviceA-GigabitEthernet1/0/1] port trunk permit vlan all
# Enable GVRP on trunk port GigabitEthernet 1/0/1.
[DeviceA-GigabitEthernet1/0/1] gvrp
[DeviceA-GigabitEthernet1/0/1] quit
# Create VLAN 2 (a static VLAN).
[DeviceA] vlan 2
[DeviceA-vlan2] quit
2. Configure Device B.
# Enable GVRP globally.
<DeviceB> system-view
[DeviceB] gvrp
# Configure port GigabitEthernet 1/0/1 as a trunk port, and assign it to all VLANs.
[DeviceB] interface gigabitethernet 1/0/1
[DeviceB-GigabitEthernet1/0/1] port link-type trunk
[DeviceB-GigabitEthernet1/0/1] port trunk permit vlan all
