HP A5120 EI Series Configuration Guide

122
Verification
1. The hosts and the server in VLAN 100 can ping one another successfully. The hosts and the server
in VLAN 200 can ping one another successfully. The hosts/server in VLAN 100 cannot ping the
hosts and the server in VLAN 200, and vice versa.
2. Display protocol-based VLAN information on Device to determine whether the configurations have
become valid.
# Display protocol-based VLAN configuration on Device.
[Device-GigabitEthernet1/0/2] display protocol-vlan vlan all
VLAN ID:100
Protocol Index Protocol Type
======================================================
1 ipv4
VLAN ID:200
Protocol Index Protocol Type
======================================================
1 ipv6
# Display protocol-based VLAN information on the ports of Device.
[Device-GigabitEthernet1/0/2] display protocol-vlan interface all
Interface: GigabitEthernet 1/0/1
VLAN ID Protocol Index Protocol Type
======================================================
100 1 ipv4
200 1 ipv6
Interface: GigabitEthernet 1/0/2
VLAN ID Protocol Index Protocol Type
======================================================
100 1 ipv4
200 1 ipv6
Configuration guidelines
Protocol-based VLAN configuration applies to hybrid ports only.
IP Subnet-based VLAN configuration
Introduction
In this approach, packets are assigned to VLANs based on their source IP addresses and subnet masks. A
port configured with IP subnet-based VLANs assigns a received untagged packet to a VLAN based on the
source address of the packet.
This feature is used to assign packets from the specified network segment or IP address to a specific
VLAN.
Configuring an IP subnet-based VLAN

HP A5120 EI Series Specifications

General

Uplink Ports	4 x SFP
Stacking	No
Management	CLI, Web, SNMP
Routing Protocols	RIP, OSPF
Power Supply	AC
MAC Address Table Size	16K
Dimensions	440 x 430 x 44 mm
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
Model	HP A5120-24G EI Switch (JG234A)
VLANs	4094
