HP A5120 EI Series Configuration Guide

176
To do…
Use the command…
Remarks
Configure the advertisable TLVs
lldp tlv-enable { basic-tlv { all | port-
description | system-capability | system-
description | system-name } | dot1-tlv { all
| port-vlan-id | protocol-vlan-id [ vlan-id ] |
vlan-name [ vlan-id ] } | dot3-tlv { all | link-
aggregation | mac-physic | max-frame-size
| power } | med-tlv { all | capability |
inventory | location-id { civic-address
device-type country-code { ca-type ca-value
}&<1–10> | elin-address tel-number } |
network-policy | power-over-ethernet } }
Optional
By default, all types of
LLDP TLVs except the
location identification
TLVs are advertisable
on a Layer 2 Ethernet
port.
Configuring the management address and its encoding format
LLDP encodes management addresses in numeric or character string format in management address TLVs.
By default, management addresses are encoded in numeric format. If a neighbor encoded its
management address in character string format, you must configure the encoding format of the
management address as string on the connecting port to guarantee normal communication with the
neighbor.
Follow these steps to configure a management address to be advertised and its encoding format on one
or a group of ports:
To do…
Use the command…
Remarks
Enter system view
system-view
—
Enter
Ethernet
interface
view or port
group view
Enter Layer 2
Ethernet interface
view
interface interface-type
interface-number
Required
Use either command.
Enter port group
view
port-group manual port-group-
name
Allow LLDP to advertise the
management address in LLDPDUs
and configure the advertised
management address
lldp management-address-tlv [
ip-address ]
Optional
By default, the management
address is sent through LLDPDUs.
For a Layer 2 Ethernet port, the
management address is the main
IP address of the lowest-ID VLAN
carried on the port. If none of the
carried VLANs is assigned an IP
address, no management address
will be advertised.
Configure the encoding format of the
management address as character
string
lldp management-address-
format string
Optional
By default, the management
address is encapsulated in the
numeric format.

HP A5120 EI Series Specifications

General

Uplink Ports	4 x SFP
Stacking	No
Management	CLI, Web, SNMP
Routing Protocols	RIP, OSPF
Power Supply	AC
MAC Address Table Size	16K
Dimensions	440 x 430 x 44 mm
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
Model	HP A5120-24G EI Switch (JG234A)
VLANs	4094
