160
To do...
Use the command...
Remarks
Enter port group
view
port-group manual port-group-name
Configure VLAN transparent
transmission on the ports
qinq transparent-vlan vlan-list
Required
By default, VLAN transparent
transmission is not
configured.
NOTE:
When you are configuring transparent transmission for a VLAN, you must configure all the switches on
the transmission path to permit packets of this VLAN to pass through.
Configuring selective QinQ
Configuring an outer VLAN tagging policy
Basic QinQ can only tag received frames with the PVID of the receiving port. Selective QinQ allows
adding different outer VLAN tags based on different inner VLAN tags.
The A5120 EI Switch Series supports the configuration of basic QinQ and selective QinQ at the same
time on a port. When both features are enabled on the port, frames that meet the selective QinQ
condition are handled with selective QinQ before the remaining frames are handled with basic QinQ.
Follow these steps to configure an outer VLAN tagging policy:
To do...
Use the command...
Remarks
Enter system view
system-view
Enter interface
view or port
group view
Enter Ethernet
or Layer-2
aggregate
interface view
interface interface-type interface-
number
Required
Use either command
Enter port
group view
port-group manual port-group-
name
Enter QinQ view and configure the
SVLAN tag for the port to add
qinq vid vlan-id
Required
By default, the SVLAN tag to be
added is the PVID of the
receiving port.
Tag frames of the specified
CVLANs with the current SVLAN
raw-vlan-id inbound { all | vlan-
list }
Required
CAUTION:
An inner VLAN tag corresponds to only one outer VLAN tag.
To change an outer VLAN tag, you must delete the old outer VLAN tag configuration and configure a new outer
VLAN tag.
