Statistics commands 74
GEA Layer 3 statistics
The following command displays GEA statistics:
show ip gea
Command mode: All except User EXEC
GEA L3 statistics:
Max L3 table size : 4096
Number of L3 entries used : 9
Max LPM table size : 4097
Number of LPM entries used : 31
Max block in LPM table : 255
Number of blocks used in LPM table: 24
Management Processor statistics
The following table describes the MP-specific Statistics commands. The following sections provide more detailed
information and commands.
Table 66 MP-specific Statistics commands
Command Usage
show mp packet
Displays packet statistics, to check for leads and load.
Command mode: All
show mp tcp-block
Displays all Transmission Control Protocol (TCP) control blocks (TCB) that are in use.
Command mode: All
show mp udp-block
Displays all User Datagram Protocol (UDP) control blocks (UCB) that are in use.
Command mode: All
show mp cpu
Displays CPU utilization for periods of up to 1, 4, and 64 seconds.
Command mode: All
Packet statistics
The following command displays packet statistics:
show mp packet
Command mode: All except User EXEC
Packet counts:
allocs: 36692 frees: 36692
mediums: 0 mediums hi-watermark: 3
jumbos: 0 jumbos hi-watermark: 0
smalls: 0 smalls hi-watermark: 2
failures: 0
The following table describes the packet statistics.
Table 67 MP specific packet statistics
Description Example statistic
allocs Total number of packet allocations from the packet buffer pool by the TCP/IP protocol stack.
frees Total number of times the packet buffers are freed (released) to the packet buffer pool by the
TCP/IP protocol stack.
mediums Total number of packet allocations with size between 128 to 1536 bytes from the packet buffer
pool by the TCP/IP protocol stack.
