Statistics commands 75
Table 67 MP specific packet statistics
Description Example statistic
mediums hi-watermark The highest number of packet allocation with size between 128 to 1536 bytes from the packet
buffer pool by the TCP/IP protocol stack.
jumbos Total number of packet allocations with more than 1536 bytes from the packet buffer pool by
the TCP/IP protocol stack.
jumbos hi-watermark The highest number of packet allocation with more than 1536 bytes from the packet buffer pool
by the TCP/IP protocol stack.
smalls Total number of packet allocations with size less than 128 bytes from the packet buffer pool by
the TCP/IP protocol stack.
smalls hi-watermark The highest number of packet allocation with size less than 128 bytes from the packet buffer
pool by the TCP/IP protocol stack.
failures Total number of packet allocation failures from the packet buffer pool by the TCP/IP protocol
stack.
TCP statistics
The following command displays TCP statistics:
show mp tcp-block
Command mode: All except User EXEC
All TCP allocated control blocks:
10ad41e8: 0.0.0.0 0 <=> 0.0.0.0 80 listen
10ad5790: 47.81.27.5 1171 <=> 47.80.23.243 23 established
The following table describes the Transmission Control Protocol (TCP) control block (TCB) statistics shown in this
example:
Table 68 TCP statistics
Description Example statistic
Memory 10ad41e8/10ad5790
Destination IP address 0.0.0.0/47.81.27.5
Destination port 0/1171
Source IP 0.0.0.0/47.80.23.243
Source port 80/23
State listen/established
UDP statistics
The following command displays UDP statistics:
show mp udp-block
Command mode: All except User EXEC
All UDP allocated control blocks:
161: listen
The following table describes the User Datagram Protocol (UDP) control block (UCB) statistics shown in this example:
Table 69 UDP statistics
Description Example Statistic
Control block 161
State listen
