Figure 1 BL860c Server Blade Components
6
Processors
1
SAS backplane
2
DIMMs
7
System board
8
Trusted Platform module
3
Mezzanine card 1
4
Mezzanine card 2
9
Front display panel
105
SAS disk drivesMezzanine card 3
SAS Disk Drives
There are two SAS disk drive slots on the server blade. The SAS disk drives have identical LEDs
that show the drive status.
Figure 2 shows the slot numbers of the SAS hard disk drives.
Server Blade Components 15
