Figure 4 shows the front panel LEDs.
Figure 4 Front Panel LEDs on the Server Blade
6
NIC 3 LED
4
NIC 1 LED
1
UID LED
2 7
Server health LED NIC 4 LED
5
NIC 2 LED
3
Internal health LED
Table 5 details the functions of the front panel LEDs.
Table 5 BL860c Server Blade Front Panel
LED DescriptionItem
Unit identification (UID)1
Server health2
Internal health3
NIC 14
NIC 25
NIC 36
NIC 47
SAS Disk Drive LEDs
There are two SAS disk drives on the server blade. They have identical LEDs that show the drive
status.
Figure 5 shows the locations of the SAS disk drive LEDs.
Controls, Ports, and LEDs 21
