HP Integrity BL860c - Front Panel Controls and Ports

Figure 5 SAS Disk Drive LEDs
21
Status LEDActivity LED
Controls and Ports
The following section identifies the locations and functions of the front panel controls and ports.
The Power button, and server blade extraction lever, and the SUV cable port are located on the
front of the server. For more information about the Power button and server blade power states,
see “Server Power States” (page 39).
Figure 6 Front Panel Controls and Ports
5
SUV port
3
iLO 2 MP reset pinhole
button
1
Extraction lever release
button
6
Init (ToC) pinhole button
42
Extraction leverPower button
