HP Integrity BL860c User Manual

A Parts Information
This appendix provides parts information for the HP Integrity BL860c server blade components
(customer replaceable units [CRUs]).
Server Blade Components List
Table 29 details the part numbers of the components (or CRUs) in the server blade.
NOTE: Part numbers are found by using the part nomenclature from this list to select the correct
part from the HP Partsurfer. If a part that is not listed in the CRU list needs to be replaced, the Base
Unit Repair Kit is required. Remove processors, DIMMs and HDDs, and transfer these to the new
base unit.
Table 29 CRU List
Exchange Part
Number
Replacement
Part Number
Manufacturing Part
Number
Description
Memory
AB563–69001AB563AX512 MB DDR2 memory
AB564–69002AB564BX1 GB DDR2 memory
AB565–69002AB565BX2 GB DDR2 memory
AB566–69002AB566BX4 GB DDR2 memory
Processors
AD272–69001AD272–2107BAD272–2107BItanium CPU 1.6 GHz 3 MB
AD271–69001AD271–2101BAD271–2101BItanium CPU 1.4 GHz 12 MB
AD270–69001AD270–2101BAD270–2101BItanium CPU 1.6 GHz 18 MB
AD394–69001AD394–2101CNAD394–2101CItanium CPU 1.42 GHz 12 MB dual core
AD395–69001AD395–2102CNAD395–2102CItanium CPU 1.6 GHz 12 MB single core
AD396–69001AD396–2101CNAD396–2101CItanium CPU 1.67 GHz 18 MB dual core
Internal Disks
376596–001375860–B2136 GB, 10k RPM SAS hot-plug disk
432322–001431934–B2136 GB, 15k RPM SAS hot-plug disk
376597–001375862–B2172 GB, 10k RPM SAS hot-plug disk
432321–001431936–B2172 GB, 15k RPM SAS hot-plug disk
432320–001431959–B21146 GB, 10k RPM SAS hot-plug disk
Boards and Cards
AD217–69001AD217–67001AD217–60001Rev. A. BL860c system board
AD217–60101Rev. B. BL860c system board
• AD217-69101
• AD217-69301
AD217–67003AD217–600032 disk drive SAS backplane
AD217–67002AD217–2002BFront panel display assembly
405920–001405920–001N411419–B21Dual-port 4 Gbps FC mezzanine card
