Table 15 Server Blade Front Panel LEDs (continued)
StatusLED DescriptionItem
Off = Not flagged
Off = Power is offServer health2
Steady Green = Power is on
Flashing Amber = Server is degraded (power is on or off)
Flashing Red = Server critical (power is on or off)
Green = OnInternal health3
Amber = Standby power (main power off, iLO 2 MP power on)
Flashing Red = Critical internal error
Off = Unit off (no power from enclosure)
Steady Green = Linked to networkNIC 14 – 7
Flashing Green = Network activityNIC 2
Off = No network activityNIC 3
NIC 4
Locator LED
The locator LED, or unit identifier (UID) allows a specific server blade to be identified in a rack or
data center environment. One Locator LED is located in the front panel.
Table 16 Locator LED Status
StatusLED Description
IdentificationSteady Blue
Not flaggedOff
NOTE: When the UID is lit, this also indicates that the BMC is working properly.
Server Health LED
The server blade uses the Server Health LED for the following reasons:
• To carry forward the Attention functionality of legacy Integrity front panel designs.
• To indicate whether the server is on or off.
• To provide a visual alert for faults that software/firmware is not sure if a FRU must be
reseated/replaced.
The server health LED indicates the overall health state of the server blade, including the state of
server firmware and the OS. If the LED is amber or red, the server blade needs attention. Examine
the event logs (on iLO 2 MP) for details of the problem. Table 17 details the functions of the health
LED.
Table 17 Server Health LED States
StatusFlash RateLED
Server blade is offLED Off
Server blade has left the firmware boot, and an OS is booting or running with no failures
(since SEL logs last examined)
SteadyGreen
A warning or critical failure has been detected and loggedFlash (1/sec)Amber
A fatal fault has been detected and loggedFlash (2/sec)Red
92 Troubleshooting
