HP M525

5. Remove two screws (callout 1) and then release the ADF cable from its retainers (callout 2).
Figure 1-129 Remove the ADF cable (3 of 5)
1
2
6. Open the formatter cage.
Figure 1-130 Remove the ADF cable (4 of 5)
ENWW
Removal and replacement procedures
85
