284 HP ProLiant ML370 Generation 4 Server Reference and Troubleshooting Guide
1. Connect to the service port. For more information, refer to the
HP BladeSystem Maintenance and Service Guide on the HP website
(http://www.hp.com/products/servers/proliant-bl/p-class/info
).
2. Access the diagnostics. For more information, refer to the HP BladeSystem
Maintenance and Service Guide on the HP website
(http://www.hp.com/products/servers/proliant-bl/p-class/info
).
Server blade management module error codes
List of messages:
Server blade error codes .............................................................................................................284
Server blade management module board error codes.................................................................285
Server blade management module signal backplane error codes ...............................................285
Server blade management module power backplane A error codes...........................................285
Server blade management module power backplane B error codes ...........................................286
Interconnect A Error Code .........................................................................................................286
Interconnect B Error Code..........................................................................................................287
Interconnect Module A (10-Connector) Error Code ..................................................................287
Interconnect Module B (10-Connector) Error Code...................................................................288
Interconnect Module A (6-Connector) Error Code ....................................................................288
Interconnect Module B (6-Connector) Error Code.....................................................................289
Unknown server blade management module error code ............................................................289
Location LED
Server blade error codes
Codes
1-1 or 1-2
2-1 or 2-2
3-1 or 3-2
Server Blade - Slot 4 4-1 or 4-2
Server Blade - Slot 5 5-1 or 5-2
Server Blade - Slot 6 6-1 or 6-2
Server Blade - Slot 7 7-1 or 7-2
8-1 or 8-2
Server Blade - Slot 1
Server Blade - Slot 2
Server Blade - Slot 3
Server Blade - Slot 8
