Figure 112 Volume Query Information (CA) Panel
Volume Query Information (TC)
Command ===> Scroll ===> PAGE
2008/03/11 19:11:45
Copy Group ID . . . . . . . . . : TC
Copy Type(in Configuration): TC Copy Type(from Storage System) : N/A
---------- Primary Volume ---------- --------- Secondary Volume ---------
SN SSID CU CCA DEVN Status Dir SN SSID CU CCA DEVN Status
14002 2340 00 0A 730A* SIMPLEX > 64050 6000 00 00 6000 N/A
C/T ID PROT MODE COPY PACE FENCE LVL Freeze SCP DIF UNIT CONSLOST(P-S)
N/A N/A N/A N/A N/A TRK N-N
Other CopyPair Information
----- Primary/Secondary ----- ---- Pair Volume ----
Type C/T ID SN DEVN Status Dir SN SSID CU CCA DEVN
******************************* Bottom of data ********************************
F1=Help F3=Exit F4=Refresh F7=Backward F8=Forward
Table 81 (page 141) describes the items in the Volume Query Information (TC) panel.
Table 81 Contents of the Volume Query Information (CA) Panel
DescriptionItem
Copy group IDCopy Group ID
Copy group type at definitionCopy Group Type (in Configuration)
Copy types held by the storage systemCopy Group Type (from Storage System)
Storage system serial number of the P-VOL at
definition
SNPrimary Volume
SSID of the P-VOL at definitionSSID
CU number of the P-VOL at definitionCU
CCA of the P-VOL at definitionCCA
Device number of the P-VOL at definition
The following volume online information is
displayed to the right of DEVN:
1
• *: Online
• -: Offline
Nothing is displayed when volume online
information cannot be obtained.
DEVN
Copy pair status
2
Status
Copy direction in the copy pair
Always displays > when the Status of the
Primary Volume is SIMPLEX.
Dir
Storage system serial number of the S-VOL at
definition
SNSecondary Volume
SSID of the S-VOL at definitionSSID
CU number of the S-VOL at definitionCU
CCA of the S-VOL at definitionCCA
Manage Copy Groups Panel (Copy Group Operation) 141
