Figure 86 Manage Route Panel
“Contents of the Manage Route Panel” (page 99) describes the items in the Manage Route panel.
Table 65 Contents of the Manage Route Panel
DescriptionItem
Specify an action.
• s: Displays the Route Status panel used to display the information on the route list ID.
AC
Route list IDRoute List ID
Extra Command Device Direct Operation Panel
In the Manage Route panel and Route Status panel, press the F5=Extra key to display the Extra
Command Device Direct Operation panel. You can use the Extra Command Device Direct Operation
panel to perform operations (aside from registration) for command devices not defined in the route
list.
Figure 87 (page 99) shows the Extra Command Device Direct Operation panel.
Figure 87 Extra Command Device Direct Operation Panel
Table 66 (page 100) describes the items displayed in the Extra Command Device Direct Operation
panel.
Manage Route Panel (Route Management) 99
