Table 48 Contents of the Select SSID Panel
DescriptionItem
Specify an action:
s: Selects a CU and SSID.
When actions are entered in multiple AC columns, the top line is specified.
AC
CU numberCU
SSIDSSID
In the initial state, the information is displayed in ascending order by EBCDIC codes in CU.
Edit Port Definition Panel
If e is specified in AC in the Edit Logical Path Definition panel, the Edit Port Definition panel is
displayed to edit physical paths.
Figure 57 (page 67) shows the Edit Port Definition panel.
Figure 57 Edit Port Definition Panel
Table 49 (page 67) describes the items in the Edit Port Definition panel.
Table 49 Contents of the Edit Port Definition Panel
DescriptionItem
Path set IDPath Set ID
Primary storage system serial numberS/NPrimary
Model of the primary storage systemModel
Primary interface versionIFType
Primary path IDPathID
Primary CU numberCU
Primary SSIDSSID
Discover/Define Configuration Panel (Configuration File Definition) 67
