Figure 43 Entire Route Information Panel
Table 35 (page 54) describes the items in the Entire Route Information panel.
Table 35 Contents of the Entire Route Information Panel
DescriptionItem
Route list ID selected in the Route Config panelRoute List ID
Specify an action.
• i – Adds an entry to the next row. The Insert Route Entry Panel is displayed.
• d – Deletes the entry
• e – Updates the entry. Displays the Edit Route Entry Panel if the specified
entry was created by the remote scan and no dummy device number has
been assigned to it. Otherwise, the Edit Remote Route Entry Panel is
displayed.
• r:— Adds an entry to be processed by remote scan to the next row.
Displays the Insert Remote Route Entry panel used to add an entry for
remote scanning to the next row.
When actions are input to multiple ACs, they are processed in the following
order:
1. Entries at the beginning of the route (the value of List is 1) for which d has
been specified
2. i, e, or r or an entry that is not at the beginning of the route and for which
d has been specified (processed in order from top to bottom)
AC
APID to which the route belongsAPID
Route numberRoute Num
Placement (list number) of the entry within the same route numberLst
DAD ID to which the entry belongsDevice Address Domain
Serial number of the storage system to which the entry belongsSerial Number
SSID of the CU to which the entry belongsSSID
CU number to which the entry belongsCU
CCA of the entryCCA
Device number of the entryDevn
54 ISPF Panels
