Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(16) Card reader board
NOTE: The card reader board bracket is available in the Bracket Kit as spare part number
M21855-001.
The card reader cable is available in the Cable Kit as spare part number N56092-001.
N12914-001
(17) Fan Kit (includes left processor fan and right graphics fan) N32583-001
Display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
Table 3-2
Display component descriptions and part numbers
Item Component Spare part number
(1) Display bezel
NOTE: Bezel protective tape is available in the Plastic Kit as spare part number N06911-001.
Models with an 5 MP + IR camera N56094-001
Models with an HD camera M21863-001
22 Chapter 3 Illustrated parts catalog
