b. Peel the wireless antennas (2) from the display back cover. The antennas are attached with
adhesive. The wireless antennas are available using spare part number N03119-001.
Display rear covers are available as the following spare part numbers:
● N56096-001—FHD, 250 nit panel
● N56097-001—FHD, 400 nit panel
● N58070-001—FHD, 250 nit panel, IR camera
● N58071-001—FHD, 400 nit panel, IR camera
● N58072-001—QHD, 300 nit panel
● N58073-001—QHD, 300 nit panel, IR camera
To reassemble and replace the display assembly, reverse this procedure.
Top cover with keyboard
The top cover with keyboard remains after removing all other spare parts from the computer. In this
section, the first table provides the main spare part number for the top covers with keyboards. The
second table provides the country codes.
Table 5-16
Top cover with keyboard descriptions and part numbers
Description Spare part number
Top cover with keyboard, backlit N52484-xx1
Top cover with keyboard, not backlit N52485-xx1
Table 5-17 Spare part country codes
For use in country or
region
Spare part
number
For use in country or
region
Spare part
number
For use in country or
region
Spare part
number
Belgium -A41 Hungary -211 Saudi Arabia -171
Brazil -201 Iceland -DD1 Slovenia -BA1
66 Chapter 5 Removal and replacement procedures for authorized service provider parts
