Table 3-3 Cable descriptions and part numbers
Item Component
Cable Kit N56092-001
(1) Card reader board cable
(2) Fingerprint reader cable
(3) NFC module cable
(4) Sensor board cable
(5) Touchpad cable
Miscellaneous parts
To identify the miscellaneous parts, use this table.
Table 3-4
Miscellaneous part descriptions and part numbers
Component Spare part number
AC adapter
150 W HP Smart Adapter (PFC, 4.5 mm, slim barrel) L32661-001
120 W HP Smart Adapter (PFC, RC, 4.5 mm, slim barrel) M95377-001
Screw Kit M21874-001
Cable Kit (includes card reader cable, touchpad cable, NFC cable, fingerprint reader cable, and
sensor cable)
N56092-001
Bracket Kit (includes battery support bracket, card reader bracket, fingerprint reader module
bracket, I/O bracket, and touchpad bracket)
M21855-001
Plastic Kit (includes RJ-45 cover, fingerprint reader insert, card reader insert, display bezel caps,
display bezel protective tape, touchpad conductive tape, and WLAN protective shield)
N06911-001
Rubber Kit (includes microphone rubber with mesh) N56098-001
NFC adhesive M31730-001
USB External DVD±RW drive 747080-001
Adapters
USB-C®-to-DisplayPort™ adapter 831753-001
USB-C-to-USB 3.0 adapter 814618-001
USB-C-to-VGA adapter 831751-001
USB-C-to-USB-A L65254-001
USB-C-to-RJ-45 adapter M95985-001
USB-C-to-RJ-45 adapter (FD) 918779-001
USB-C-to-HDMI 2.0 adapter 935325-001
HDMI-to-VGA adapter 701943-001
HDMI-to-DVI adapter 749038-001
24 Chapter 3 Illustrated parts catalog
