Table 10-2 Display specifications
Metric U.S.
Active diagonal size 39.6 cm 15.6 in
Resolution 1920 × 1080 (FHD)
2560 × 1440 (QHD)
Surface treatment Antiglare
Brightness 250 nits or 400 nits (FHD panels)
300 nits (QHD panels)
Viewing angle UWVA
Backlight WLED or LED
Display panel interface eDP
Solid-state drive specifications
This section provides specifications for your solid-state drives.
Table 10-3
Solid-state drive specifications
512 GB* 1 TB* 2 TB* 4 TB*
Dimensions
Height 1.0 mm 1.0 mm 1.0 mm 1.0 mm
Length 50.8 mm 50.8 mm 50.8 mm 50.8 mm
Width 28.9 mm 28.9 mm 28.9 mm 28.9 mm
Weight < 10 g < 10 g 8 g 8 g
Interface type PCIe PCIe PCIe PCIe
Ready time, maximum (to not busy) < 1.0 ms 1.0 ms 1.0 ms 1.0 ms
Access times, logical 0.1 ms 0.1 ms 0.1 ms 0.1 ms
Transfer rate
Sequential read Up to 2150
MBps
Up to 2150 MBps Up to 3500 MBps Up to 3500 MBps
Random read Up to 300,000
IOPs
Up to 300,000 IOPs Up to 430,000 IOPs Up to 620,000 IOPs
Sequential write Up to 1550
MBps
Up to 1550 MBps Up to 2800 MBps Up to 2800 MBps
Random write Up to 100,000
IOPs
Up to 100,000 IOPs Up to 390,000 IOPs Up to 500,000 IOPs
Total logical sectors 1,000,215,216 1,500,336,388 3,000,723,328 6,001,730,164
Operating temperature 0°C to 70°C (32°F to 158°F)
*1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less. Actual drive
specifications might differ slightly.
Solid-state drive specifications 157
