192
When the maximum number of secure MAC address entries is reached, the port changes to secure
mode. In secure mode, the port cannot add or learn any more secure MAC addresses. The port
allows only frames sourced from secure MAC addresses or MAC addresses configured by using the
mac-address dynamic or mac-address static command to pass through.
Table 16 A comparison of static, sticky, and dynamic secure MAC addresses
Type Address sources Aging mechanism
Can be saved
an
d survive a
device reboot?
Static
Manually added (by using the
port-security
mac-address
security
command without
the
sticky
keyword).
Not available.
The static addresses
never age out
unless you perform any of the following
tasks:
• Manually remove these MAC
addresses.
• Change the port security mode.
• Disable the port security feature.
Yes.
Sticky
• Manually added (by
using the port-security
mac-address security
command with the
sticky keyword).
• Converted from dynamic
secure MAC addresses.
• A
utomatically learned
when the dynamic
secure MAC feature
(port-security
mac-address dynamic)
is disabled.
By default, sticky MAC addresses do not
age out. However, you can configure an
aging timer or use the aging timer
together with the inactivity aging feature
to delete old sticky MAC addresses.
• If only the aging timer is configured,
the
aging timer counts up
regardless of whether traffic data
has been sent from the sticky MAC
address.
•
If both the aging timer and the
inactivity aging feature are
configured, the aging timer restarts
once traffic data is detected from
the sticky MAC address.
Yes.
T
he secure MAC
aging timer restarts
at a reboot.
Dynamic
•
Converted from sticky
MAC addresses.
• A
utomatically learned
after the dynamic secure
MAC feature is enabled.
Same as sticky MAC addresses.
No.
All dynamic secure
MAC addresses are
lost at reboot.
Configuration prerequisites
Before you configure secure MAC addresses, complete the following tasks:
• Enable port security.
• Set port security's limit on the number of MAC addresses on the port. Perform this task before
you enable autoLearn mode.
• Set the port security mode to autoLearn.
• Configure the port to permit packets of the specified VLAN to pass or add the port to the VLAN.
Make sure the VLAN already exists.
Configuration procedure
To configure a secure MAC address:
