90
Configuration prerequisites
Before you configure an 802.1X Auth-Fail VLAN, complete the following tasks:
• Create the VLAN to be specified as the 802.1X Auth-Fail VLAN.
• If the 802.1X-enabled port performs MAC-based access control, perform the following
operations for the port:
ï‚¡ Configure the port as a hybrid port.
ï‚¡ Enable MAC-based VLAN on the port. For more information about the MAC-based VLAN
feature, see Layer 2—LAN Switching Configuration Guide.
ï‚¡ Assign the port to the Auth-Fail VLAN as an untagged member.
Configuration procedure
To configure an 802.1X Auth-Fail VLAN:
1. Enter system view.
N/A
2.
view.
interface
interface-type
interface-number
N/A
3. Configure the 802.1X
Auth-Fail VLAN on the port.
dot1x auth-fail vlan
authfail-vlan-id
By default, no 802.1X Auth-Fail
VLAN is configured.
Configuring an 802.1X critical VLAN
Configuration guidelines
When you configure an 802.1X critical VLAN, follow these restrictions and guidelines:
• Assign different IDs to the voice VLAN, the PVID, and the 802.1X critical VLAN on a port. The
assignment makes sure the port can correctly process VLAN-tagged incoming traffic.
• You can configure only one 802.1X critical VLAN on a port. The 802.1X critical VLANs on
different ports can be different.
• You cannot specify a VLAN as both a super VLAN and an 802.1X critical VLAN. For information
about super VLANs, see Layer 2—LAN Switching Configuration Guide.
Configuration prerequisites
Before you configure an 802.1X critical VLAN, complete the following tasks:
• Create the VLAN to be specified as a critical VLAN.
• If the 802.1X-enabled port performs MAC-based access control, perform the following
operations for the port:
ï‚¡ Configure the port as a hybrid port.
ï‚¡ Enable MAC-based VLAN on the port. For more information about the MAC-based VLAN
feature, see Layer 2—LAN Switching Configuration Guide.
ï‚¡ Assign the port to the 802.1X critical VLAN as an untagged member.
