The installation is complete.
Installing the 2 NVMe Slim SAS riser option
Prerequisites
Before you perform this procedure, make sure that you have the following items available:
• The components included with the hardware option kit
• T-10 Torx screwdriver
Procedure
1.
Power down the server.
2.
Do one of the following:
• Disconnect each power cord from the power source.
• Disconnect each power cord from the server.
3.
Do one of the following:
• Extend the server from the rack.
• Remove the server from the rack.
4.
Remove the access panel.
5. Using the labels on the cable, connect the cables to the riser.
6. Install the tertiary riser cage.
7. Connect the cable to the drive backplane.
The installation is complete.
106
Hardware options installation
