Cabling
HPE ProLiant Gen10 Plus DL Servers Storage Cabling Guidelines
When installing cables, observe the following:
• All ports are labeled:
◦ System board ports
◦ Controller ports
◦ 12G SAS Expander ports
• Most data cables have labels near each connector with destination port information.
• Some data cables are pre-bent. Do not unbend or manipulate the cables.
• Before connecting a cable to a port, lay the cable in place to verify the length of the cable.
• When routing cables from the front to the rear of the server, use the cable channels on either side of the chassis.
Cabling diagrams
Use the following tables to find cabling information and diagrams. For additional cabling configurations, see
https://
www.hpe.com/info/proliantcablingmatrix.
Table 1: SAS/SATA options
Option kit
Cable part number From To
Optical disk drive, Slim
SATA cable
756914-001 Optical disk drive System board
2 SFF Slim SAS SAS/SATA
Universal Media Bay
P22760-001 Universal Media Bay System board
2 SFF Slim SAS x8 SAS/
SATA Universal Media Bay
P22761-001 2 SFF Side by Side
backplane
System board
Table 2: LFF/SFF x4 SAS Cable options
Option kit
Cable part number From To
x8 Mini SAS cable to x8 Mini
SAS cable (x4)
747568-001 8 SFF SAS/SATA option, box
3
HPE Smart Array P408i-a or
P816i-a Gen10 Controller,
ports 1 and 2
x8 Mini SAS cable to x8 Mini
SAS cable (x4)
747568-001 8 SFF SAS/SATA option, box
3
HPE 12GB SAS Expander
Card, ports 3 and 4 in the
primary riser cage
Table Continued
124 Cabling
