Component identification
Front panel components
SFF front panel components
Item Description
1 Box 1 (optional drives or universal media bay)
2 Box 2 (optional drives)
3 Box 3 drives 1 through 8
4 Serial label pull tab or optional Systems Insight Display
5 iLO service port
6 USB 31 Gen1 port
Universal media bay components
Item
Description
1 USB 20 port
2 Video display port
3 Optical disc drive (optional)
4 Drives (optional)
8 Component identification
