HPE ProLiant DL385 Gen10 Plus

Item Description
3 Display port/USB connector
4 Primary (processor 1) PCIe riser connector
5 x2 SATA port 1
6 NVMe port 8A
7 x1 SATA port 2
8 Front power/USB 31 Gen1 connector
9 Optical/SATA port 3
10 DIMMs
11 Processor 1
12 Drive backplane power connectors
13 NVMe port 2A
14 NVMe port 1A
15 Energy Pack connector
16 NVMe port 2B
17 NVMe port 1B
18 DIMMs
19 Processor 2
20 NVMe port 1C
21 NVMe port 2C
22 Drive backplane power connector
23 Chassis Intrusion Detection connector
24 Dual USB port
25 Flexible Smart Array connector
26 Tertiary (processor 2) PCI riser connector
27 Secondary (processor 2) PCIe riser connector
28 System battery
29 Serial port connector
System maintenance switch descriptions
Position
Default Function
S1
1
O • O = iLO security is enabled.
• On = iLO security is disabled.
S2 O Reserved
Table Continued
20 Component identification
