Description Status
AMP status LED • O = AMP modes disabled
• Solid green = AMP mode enabled
• Solid amber = Failover
• Flashing amber = Invalid configuration
Power cap LED • O = System is in standby, or no cap is set
• Solid green = Power cap applied
1
For Networking Choice server models, the embedded NIC ports are not equipped on the server. Therefore, the NIC LEDs on the Systems
Insight Display will flash based on the FlexibleLOM network port activity. In the case of a dual‑port FlexibleLOM, only NIC LED 1 and 2
will illuminate to correspond with the activity of the respective network ports.
When the health LED on the front panel illuminates either amber or red, the server is experiencing a health event. For
more information on the combination of these LEDs, see Systems Insight Display combined LED descriptions.
Systems Insight Display combined LED descriptions
The combined illumination of the following LEDs indicates a system condition:
• Systems Insight Display LEDs
• System power LED
• Health LED
Systems Insight Display LED
and color
Health LED System power
LED
Status
Processor (amber) Red Amber One or more of the following conditions
might exist:
• Processor in socket X has failed.
• Processor X is not installed in the
socket.
• Processor X is unsupported.
• ROM detects a failed processor during
POST.
Processor (amber) Amber Green Processor in socket X is in a pre-failure
condition.
DIMM (amber) Red Green One or more DIMMs have failed.
DIMM (amber) Amber Green DIMM in slot X is in a pre-failure condition.
Over temp (amber) Amber Green The Health Driver has detected a
cautionary temperature level.
Table Continued
16 Component identification
