Item Description Status
3 Health LED
1
• Solid green = Normal
• Flashing green (1 Hz/cycle per sec) = iLO is rebooting
• Flashing amber = System degraded
• Flashing red (1 Hz/cycle per sec) = System critical
2
4 Power On/Standby button and
system power LED
1
• Solid green = System on
• Flashing green (1 Hz/cycle per sec) = Performing power on
sequence
• Solid amber = System in standby
• O = No power present
3
1
When all four LEDs described in this table flash simultaneously, a power fault has occurred.
2
If the health LED indicates a degraded or critical state, review the system IML or use iLO to review the system health status.
3
Facility power is not present, the power cord is not attached, no power supplies are installed, power supply failure has occurred, or the
power button cable is disconnected.
UID button functionality
The UID button can be used to display the Server Health Summary when the server will not power on. For more
information, see the latest HPE iLO 5 User Guide on the Hewlett Packard Enterprise website.
Power fault LEDs
The following table provides a list of power fault LEDs, and the subsystems that are aected. Not all power faults are used
by all servers.
Subsystem
LED behavior
System board 1 flash
Processor 2 flashes
Memory 3 flashes
Riser board PCIe slots 4 flashes
FlexibleLOM 5 flashes
Removable HPE Flexible Smart Array controller 6 flashes
System board PCIe slots 7 flashes
Power backplane or storage backplane 8 flashes
Power supply 9 flashes
Systems Insight Display LEDs
The Systems Insight Display LEDs represent the system board layout. The display enables diagnosis with the access panel
installed.
14
Component identification
