9. Connect the power cable.
10.
Install a storage controller.
11.
Connect the data cables from the drive backplane to the controller.
12.
Install drives or drive blanks.
The installation is complete.
Installing a front 8 SFF SAS/SATA drive cage in box 1
Prerequisites
Before you perform this procedure, make sure that you have the following items available:
• T-10 Torx screwdriver
• The components included with the hardware option kit
Procedure
1.
Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
•
Extend the server from the rack.
•
Remove the server from the rack.
4. Remove the access panel.
Hardware options installation
65
