HPE ProLiant DL385 Gen10 Plus

Option kit Cable part number From To
x8 Mini SAS cable to x8 Mini
SAS cable (x4)
776402-001 8 SFF SAS/SATA option, box
1 or 2
HPE Smart Array P816i-a
Gen10 Controller, ports 3
and 4
x8 Mini SAS cable to x8 Mini
SAS cable (x4)
776402-001 8 SFF SAS/SATA option, box
1 or 2
HPE 12GB SAS Expander
Card, ports 3 and 4 in the
primary riser cage
x8 Mini SAS cable to x8 Mini
SAS cable (x4)
P22897-001 HPE Smart Array P408i-a or
P816i-a Gen10 Controller,
ports 1 and 2
HPE 12GB SAS Expander
Card, ports 1 and 2 in the
primary riser cage
Mini SAS straight to Mini
SAS straight cable
P22898-001 HPE Smart Array P408i-a or
P816i-a Gen10 Controller,
ports 1 and 2
HPE 12GB SAS Expander
Card, ports 1 and 2 in the
tertiary riser cage
Mini SAS straight to Mini
SAS side exit cable
P20850-001 8 SFF SAS/SATA option –
boxes 2 and 3
HPE 12GB SAS Expander
Card, ports 3 through 6 in
the primary riser cage
x4 Mini SAS cable 869827-001 4 LFF SAS/SATA drive
backplane – boxes 1, 2, and
3
HPE Smart Array P816i-a
Gen10 Controller, ports 1, 2,
and 3
x4 Mini SAS cable 869827-001 4 LFF SAS/SATA drive
backplane – boxes 1, 2, and
3
HPE 12GB SAS Expander
Card, ports 3, 4, and 5 in the
secondary or tertiary riser
cages
x4 Mini SAS cable P22899-001 4 LFF SAS/SATA drive
backplane – boxes 1, 2, and
3
HPE Smart Array P816i-a
Gen10 Controller, ports 1, 2,
and 3
x4 Mini SAS cable P22899-001 4 LFF SAS/SATA drive
backplane – boxes 1, 2, and
3
HPE 12GB SAS Expander
Card, ports 3, 4, and 5 in the
primary riser cage
x4 Mini SAS cable to x4 Mini
SAS cable
869823-001 2 LFF stacked backplane HPE 12GB SAS Expander
Card, primary riser cage
Table 3: Power Switch, Display, Serial, and USB port cable options
Option kit
Cable part number From To
Power switch, USB, and
thermal sensor cable
P14312-001 SFF Front I/O module Front power/USB 31 Gen1
connector
Power switch, USB, and
thermal sensor cable
P14312-001 8 LFF Front I/O module Front power/USB 31 Gen1
connector
Systems Insight Display,
power switch board, USB,
and thermal sensor cable
P14313-001 System Insight Display Front power/USB 31 Gen1
connector
Power switch and thermal
sensor cable
P16076-001 Bezel ear switch module Front power/USB 31 Gen1
connector
Display port and USB cable P14314-001 Universal Media Bay Display port/USB connector
Table Continued
Cabling 125
