HPRT TP80K Programming Manual

15
ESC T n
[Name]
Select printing area direction in page mode.
[Format]
ASCII
ESC T n
Hex
1B 54 n
Decimal
27 84 n
[Range]
0 ≤ n ≤ 3 48 ≤ n ≤ 51
[Description]
Select direction and initial position of printing area in page mode.
n specifies the direction and initial position of printing area.
n
Print Direction
Initial Position
0,48
From left to right
A
1,49
From bottom to top
B
2,50
From right to left
C
3,51
From top to bottom
D
[Notes]
• If current mode is standard mode, setting only the internal flag will not
affect printing.
• This command can set the initial position of print content in the printing
area.
[Default]
n=0
[Reference]
ESC $, ESC L, ESCW, ESC \, GS $, GS \
