HPRT TP80K Programming Manual

38
<Function 165> GS ( k pL pH cn fn n1 n2 (cn = 49, fn = 65)
[Name]
QR Code: Select the model
[Format]
ASCII
GS ( k pL pH cn fn n1 n2
Hex
1D 28 6B pL pH cn fn n1 n2
Decimal
29 40 107 pL pH cn fn n1 n2
[Range]
(pL + pH × 256) = 4 (pL = 4, pH = 0)
cn = 49
fn = 65
n1 = 49, 50
n2 = 0
[Default]
n1 = 50, n2 = 0
[Description]
• Select the model for QR Code
n1
Function
49
Selects model 1 conversion processing.
50
Selects model 2 conversion processing.
<Function 167> GS ( k pL pH cn fn n (cn = 49, fn = 67)
[Name]
QR Code: Set the size of module
[Format]
ASCII
GS ( k pL pH cn fn n
Hex
1D 28 6B pL pH cn fn n
Decimal
29 40 107 pL pH cn fn n
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 49
fn = 67
1 ≤ n ≤ 16
[Default]
n = 3
[Description]
Set the size of the module for QR Code to n dots.
