HPRT TP80K Programming Manual

40
<Function 181> GS ( k pL pH cn fn m (cn = 49, fn = 81)
[Name]
QR Code: Print the symbol data in the symbol storage area
[Format]
ASCII
GS ( k pL pH cn fn m
Hex
1D 28 6B pL pH cn fn m
Decimal
29 40 107 pL pH cn fn m
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 49
fn = 81
m = 48
[Description]
Encodes and prints the QR Code symbol data in the symbol storage area with
GS ( k <Function 180>.
[Note]
User must secure the quiet zone (left, right, upward, and downward space
areas defined by the QR Code symbol specifications) for QR Code printing.
<Function 182> GS ( k pL pH cn fn m (cn = 49, fn = 82)
[Name]
QR Code: Transmit the size information of the symbol data in the symbol
storage area.
[Format]
ASCII
GS ( k pL pH cn fn m
Hex
1D 28 6B 03 00 31 52 m
Decimal
29 40 107 3 0 49 82 m
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 49
fn = 82
m = 48
[Description]
Transmits the size information for the encoded QR Code symbol data in the
symbol storage area with GS ( k <Function 180>.
[Note]
This function does not print data.
The size information does not include the quiet zone (left, right, upward, and
downward space areas defined by the QR Code symbol specifications).
