HPRT TP80K Programming Manual

66
GS r n
[Name]
Transmit status
[Format]
ASCII
GS r n
Hex
1D 72 n
Decimal
29 114 n
[Range]
n=1,49
[Description]
Transmits the status.
n
Function
1,49
Transmits paper sensor status.
2, 50
Transmits drawer kick-out connector status
[Note]
This command is only valid for serial printer.
Since this command is executed after the data is processed in the receive
buffer, there may be a time lag between data reception and status
transmission.
transmit 1 byte of status data specified by n as follows:
Paper sensor status( n = 1，49 )：
Bit
0/1
Hex
Decimal
Status
0,1
0
00
0
Paper roll sensor: paper end
1
03
3
Paper roll sensor: paper adequate
2,3
0
00
0
Not used. Fixed to Off
0
00
0
Not used. Fixed to Off
4
0
00
0
Not used. Fixed to Off
5,6
-
-
-
Undefined
7
0
00
0
Not used. Fixed to Off
The status to be transmitted is as follows:
Drawer kick-out connector status (n = 2, 50)
Bit
0/1
Hex
Decimal
Status
0
0
00
0
Drawer kick-out connector pin 3 is LOW.
1
01
1
Drawer kick-out connector pin 3 is HIGH.
1-3
-
-
-
Undefined.
4
0
00
0
Not used. Fixed to Off.
5, 6
-
-
-
Undefined.
7
0
00
0
Not used. Fixed to Off.
[Reference]
DLE EOT，GS a
