HPRT TP80K Programming Manual

35
<Function 067> GS ( k pL pH cn fn n (cn = 48, fn = 67)
[Name]
PDF417: Set the width of the module.
[Format]
ASCII
GS ( k pL pH cn fn n
Hex
1D 28 6B 03 00 30 43 n
Decimal
29 40 107 3 0 48 67 n
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 67
2 ≤ n ≤ 8
[Default]
n=3
[Description]
Sets the width of the module for PDF417 to n dots.
<Function 068> GS ( k pL pH cn fn n (cn = 48, fn = 68)
[Name]
PDF417: Set the row height
[Format]
ASCII
GS ( k pL pH cn fn n
Hex
1D 28 6B 03 00 30 44 n
Decimal
29 40 107 3 0 48 68 n
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 68
2 ≤ n ≤ 8
[Default]
n=3
[Description]
Sets the row height for PDF417 to [n × (the width of the module)]
