HPRT TP80K Programming Manual

36
<Function 069> GS ( k pL pH cn fn n (cn = 48, fn = 69)
[Name]
PDF417: Set the error correction level
[Format]
ASCII
GS ( k pL pH cn fn n
Hex
1D 28 6B 04 00 30 45 n
Decimal
29 40 107 4 0 48 69 n
[Range]
(pL + pH × 256) = 4 (pL = 4, pH = 0)
cn = 48
fn = 69
m = 48, 49
48 ≤ n ≤ 56 [m =48]
0 ≤ n ≤ 40 [m =48]
[Default]
m=49, n=1
[Description]
Sets the error correction level for PDF417.
• Error correction level specified by “level” (m = 48) is as follows. The number
of the error correction codeword is fixed regardless of the number of
codewords in the data area.
n
Function
Number of error correction codewords
48
Error correction level 0
2
49
Error correction level 1
4
50
Error correction level 2
8
51
Error correction level 3
16
52
Error correction level 4
32
53
Error correction level 5
64
54
Error correction level 6
128
55
Error correction level 7
256
56
Error correction level 8
512
Error correction level specified by “ratio” (m = 49) is as follows. The error
correction level is defined by the calculated value [number of data codeword ×
n × 0.1 = (A)]. The number of the error correction codeword is changeable in
proportion to the number of the codeword in the data area.
Calculated
value (A)
Function
Number of error
correction codeword
0 ～ 3
Error correction level 1
4
4 ～ 10
Error correction level 2
8
11～20
Error correction level 3
16
21～45
Error correction level 4
32
46～100
Error correction level 5
64
101～200
Error correction level 6
128
201～400
Error correction level 7
256
401 or more
Error correction level 8
512
