order
from NV bit image 01H. Therefore, the first data group [xL xH yL yH
d1...dk] is NV bit image 01H, and the last data group [xL xH yL yH d1...dk] is
NV bit image n.The total agrees with the number of NV bit images specified by
the command FS p.
The definition data for an NV bit image consists of [xL xH yL yH d1...dk].
Therefore, when only one NV bit image is defined n=1, the printer processes a
data group [xL xH yL yH d1...dk] once. The printer uses
([data: (xL + xH × 256) × (yL + yH × 256) × 8] + [header :4]) bytes of NV
memory.
The definition area in this printer is a maximum of 64K bytes. This command
can define several NV bit images, but cannot define bit image data whose
total
The printer is busy immediately before writing into NV memory
The printer does not transmit ASB status or perform status detection during
processing of this command even when ASB is specified.
When this command is received during macro definition, the printer ends
macro definition, and begins performing this command.
Once an NV bit image is defined, it is not erased by performing ESC @, reset,
and power off.
This command performs only definition of an NV bit image and does not
perform printing. Printing of the NV bit image is performed by the FS p
command.NV bit image of each piece of space in NV memory is equal to the
size of the NV bit image data plus 4 bytes.
When bit image downloads normally, the printer will return data 0x06; While
download error occurs, the printer will return data 0x15.
