HPRT TP80K Programming Manual

GS ( L pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b
<Function 67 >
GS 8 L p1 p2 p3 p4 m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b
[Name]
Define the NV graphi cs data (raster format).
[Format]
ASCII
G S
(
L
pL
p H
m
f n
a
kc1 kc2 b xL xH yL yH [c
d1...dk]1...[c d1...dk]b
Hex
1D
28
4C
pL
p H
30
43
30
kc1 kc2 b xL xH yL yH [c
d1...dk]1...[c d1...dk]b
Decimal
29
40
76
pL
p H
48
67
48
kc1 kc2 b xL xH yL yH [c
d1...dk]1...[c d1...dk]b
ASCII
G S
8
L
p1
p2
p3
p4
m
fn a kc1 kc2 b xL xH yL
yH [c d1...dk]1...[cd1...dk]b
Hex
1D
38
4C
p1
p2
p3
p4
30
43 30 kc1 kc2 b xL xH yL
yH [c d1...dk]1...[cd1...dk]b
Decimal
29
56
76
p1
p2
p3
p4
48
67 48 kc1 kc2 b xL xH yL
yH [c d1...dk]1...[cd1...dk]b
[Range]
12 ≤ (pL + pH × 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255)
[When using GS 8 L:
12 ≤ (p1 + p2 × 256 + p3 × 65536 + p4 × 16777216) ≤ 4294967295]
m = 48, fn = 67, a = 48, a = 52 (TM-T88V only)
32 ≤ kc1 ≤ 126
32 ≤ kc2 ≤ 126
0 ≤ d ≤ 255
k = (int((xL + xH × 256) + 7)/8) × (yL + yH × 256)
[Description]
Defines the NV graphics data (raster format) as a record specified by the key codes
(kc1 and kc2) in the NV graphics area.
• b specifies the number of colors for the defined data.
• xL and xH specify the number of dots in the horizontal direction as (xL + xH ×
256)
• yL and yH specify the number of dots in the vertical direction as (yL + yH ×
256).
• c specifies the color of the defined data.
c
Color specifications
49
Color 1
50
Color 2
51
Color 3
52
Color 4
